F250HETU/FL250HETU
The Africa 4-stroke range, born from monitoring and the long Yamaha experience, has been specially developed to correspond to local conditions of use, such as muddy water or low octane fuels. Power and reliability are the hallmarks of this range of engines in a field where Yamaha is the reference brand.
Technical Specifications
MOTOR
- Engine Type : 4 temps
- Start-up : Électrique avec Prime Start™
- Max.Prop Shaft Horsepower (Kw) : 183.9 (250 ch)
DIMENSIONS
- Engine transom height (mm) : U : 770 (30.3 inch)
- Dry weight with propeller (kg) : 361
WARRANTY
- Manufacturer Warranty :
- Retail Network : YAMAHA
Models available
F250HETU
F250HETU/FL250HETU F250HETU
Technical Specifications
MOTOR |
|
| Architecture | V6 |
| Bore x Stroke (mm) | 94.0 X 80.5 |
| Displacement (cc) | 3352 |
| Engine Type | In-line 4 |
| Fuel | Wet Sump |
| Fuel consumption (L/h-tr/min) | 75.6 L/h @5500 r/min |
| Full throttle operating range (tr/min) | 5000-6000 |
| Gear Ratio | |
| Ignition System | Electronic Ignition (TCI) |
| Lubrication system | Unleaded |
| Max.Prop Shaft Horsepower (Kw) | 183.9 (250 hp) |
| Maximum Power (Kw) | |
| Number of Displacement | |
| Power system | Electronic Injection (EFI) |
| Reduction ratio | 94.0 X 80.5 |
| Reverse direction | |
| Start-up | Electric with Prime Start™ |
| Steering Control | |
| Trim method (positions) | |
 ENGINE |
|
| Max power HP/rpm | 1 |
 MORE |
|
| Alternator | 46 A |
| Control | Remote Control |
| Propeller Rotation | Sens Horaire |
DIMENSIONS |
|
| Dry weight with propeller (kg) | 361 |
| Engine Oil Capacity (L) | |
| Engine transom height (mm) | U : 770 (30.3 inch) |
| Oil capacity (L) | 4.7 L/ 4.5 L |
Equipments
EQUIPMENT |
|
| Cable end, Remote control | Yes |
| Panel Switch | Yes |
| Remocon Control | Yes |
| Service kit assy. | Yes |
REGULAR PROPELLER (3 blades) |
|
| Diameter | 14 1/2 |
| Material | STEEL |
FL250HETU
F250HETU/FL250HETU FL250HETU
Technical Specifications
MOTOR |
|
| Architecture | V6 |
| Bore x Stroke (mm) | 94.0 X 80.5 |
| Displacement (cc) | 3352 |
| Engine Type | In-line 4 |
| Fuel | Sans plomb |
| Fuel consumption (L/h-tr/min) | 75.6 L/h @5500 r/min |
| Full throttle operating range (tr/min) | 5000-6000 |
| Gear Ratio | |
| Ignition System | Electronic Ignition (TCI) |
| Lubrication system | Carter humide |
| Max.Prop Shaft Horsepower (Kw) | 183.9 (250 hp) |
| Maximum Power (Kw) | |
| Number of Displacement | |
| Power system | Injection Électronique (EFI) |
| Reduction ratio | 94.0 X 80.5 |
| Reverse direction | |
| Start-up | Électrique avec Prime Start™ |
| Steering Control | |
| Trim method (positions) | |
MORE |
|
| Alternator | 46 A |
| Control | Remote Control |
| Propeller Rotation | Counter Clockwise |
DIMENSIONS |
|
| Dry weight with propeller (kg) | 289 |
| Engine Oil Capacity (L) | |
| Engine transom height (mm) | U : 770 (30.3 inch) |
| Oil capacity (L) | 4.7 L/ 4.5 L |
Equipments
REGULAR PROPELLER (3 blades) |
|
| Diameter | 14 1/2 |
| Material | STEEL |
EQUIPMENT |
|
| Panel Switch | Yes |
| Remocon Control | Yes |
| Service kit assy. | Yes |
